Fitbit Design
Developing a Fitbit-like device with functionalities such as
monitoring blood pressure, oxygen intake, energy consumption, blood sugar level,
and dehydration requires detailed design and specific algorithms for each
function. Below is an outline of the algorithms for each function, along with a
description of the available modules and sensors in the current marketplace.
1.
Blood Pressure Monitoring
Algorithm:
- Sensor
Selection: Use a photo plethysmography (PPG) sensor and an
electrocardiogram (ECG) sensor.
- Data
Collection:
- PPG
measures the blood volume changes.
- ECG
measures the electrical activity of the heart.
- Pulse
Transit Time (PTT) Calculation:
- Calculate
the time difference between the R-peak of the ECG and the corresponding
peak in the PPG signal.
- Blood
Pressure Estimation:
- Use
the PTT to estimate systolic and diastolic blood pressure using a
regression model based on pre-calibrated data.
Modules:
- PPG
Sensors: MAX30100, MAX30102
- ECG
Sensors: AD8232, MAX30003
2.
Oxygen Intake Monitoring
Algorithm:
- Sensor
Selection: Use a PPG sensor.
- Data
Collection: Measure the light absorption at different wavelengths
(typically red and infrared).
- Oxygen
Saturation Calculation:
- Use
the ratio of the absorbance of red and infrared light to estimate the
SpO2 level using the Beer-Lambert law.
Modules:
- PPG
Sensors: MAX30100, MAX30102
3.
Energy Consumption Monitoring
Algorithm:
- Sensor
Selection: Use accelerometers and gyroscopes.
- Data
Collection: Record movement data (steps, acceleration) and heart rate.
- Energy
Expenditure Estimation:
- Use
a combination of heart rate and movement data to estimate the Metabolic
Equivalent of Task (MET).
- Calculate
energy expenditure using the formula: Calories burned=MET×weight (kg)×duration (hours)\text{Calories
burned} = \text{MET} \times \text{weight (kg)} \times \text{duration
(hours)}Calories burned=MET×weight (kg)×duration (hours)
Modules:
- Accelerometers/Gyroscopes:
MPU6050, LSM9DS1
4.
Blood Sugar Level Monitoring
Algorithm:
- Sensor
Selection: Use non-invasive glucose monitoring sensors or invasive
continuous glucose monitors (CGMs).
- Data
Collection: For non-invasive sensors, use optical sensors to measure
glucose concentration through the skin. For CGMs, use subcutaneous
sensors.
- Blood
Sugar Estimation:
- For
non-invasive sensors, use near-infrared spectroscopy and machine learning
models to estimate glucose levels.
- For
CGMs, directly read glucose levels from the sensor.
Modules:
- Non-invasive
Sensors: GlucoTrack, FreeStyle Libre (although primarily invasive)
5.
Dehydration Monitoring
Algorithm:
- Sensor
Selection: Use galvanic skin response (GSR) sensors and/or hydration
sensors.
- Data
Collection: Measure skin conductivity and/or hydration levels.
- Dehydration
Estimation:
- Analyze
the GSR data to determine changes in skin conductivity related to
dehydration.
- Use
hydration sensors to measure the water content in the skin.
Modules:
- GSR
Sensors: Grove GSR Sensor, Seeed Studio GSR Sensor
- Hydration
Sensors: LVL Hydration Monitor (not widely available in modules)
Detailed Design
1.
Hardware Architecture:
o Microcontroller: Choose a low-power microcontroller with
sufficient I/O ports and processing capabilities, such as the ESP32 or STM32.
o Power Management: Incorporate a rechargeable battery,
power management IC, and charging circuit.
o Communication: Include Bluetooth Low Energy (BLE) for
data transmission to a smartphone or other device.
o Display: Optional OLED or LCD for real-time data display.
2.
Software Architecture:
o Firmware Development: Write firmware to interface with
the sensors, collect data, and process the algorithms.
o Mobile App Development: Develop a mobile app for data
visualization, user interaction, and additional processing.
o
Available Modules and Sources
- PPG
Sensors:
- MAX30100
- MAX30102
- ECG
Sensors:
- AD8232
- MAX30003
- Accelerometers/Gyroscopes:
- MPU6050
- LSM9DS1
- GSR
Sensors:
- Grove
GSR Sensor
- Seed
Studio GSR Sensor
- Microcontrollers:
- ESP32
- STM32
- Hydration
Sensors:
- LVL
Hydration Monitor: LVL
(note: not widely available in modules)
By integrating these sensors and developing the
corresponding algorithms, you can create a comprehensive health monitoring
Fitbit-like device.
